1 frame 26 "(riser height 470mm) aviation aluminum 6061
2 charger 36V2A AC100~240v DC microphone aviation head Phi 19mm
3 controller 36V350W with protection soft start brushless power
4 meter LCD M3 can be operated by dialogue function
5 lithium ion electric 36V10AH with the protection of the power of God core cycle 500 times
6 36V350W motor brushless gear high speed 36M direct mount disc brake
7 tire KENDA la-2243 26*4.0
8 variable speed hand pull SHIMANO: ASLM310R7CT
9 pull chain SHIMANO: ARODTY300D
10 7S flywheel SHIMANO:AMFIZ217428T 7 speed flywheel
11 chain KMC E7
12 front and rear disc brakes Puruite 710
13 brake handle JAKT aluminum
14 crank 52T aluminum alloy 170mm
15 handlebar aluminum alloy 6061
16 fork aluminum alloy 6061
The 17 hub Aluminum Alloy 36M direct mounted disc brake
18 axis B910
19 support JQ007
20 battery box whitebait lithium battery box
21 life Range: 70KM with PAS
22 product size N/W: 24.5kg 1920*620*1110mm
23 packing size G/W: 27kg 1600*300*810mm |
|
